Use
Two Wheeler Three Wheeler, Bike, bicycle, with 24, 36, 48, 60 and 72 VDC system It is safe design to avoid vibrations, Fog on LCD. Bluetooth and IOT can be incorporated as per requirement
Specifications
- DC Input Voltage - Range : 9 to 15 VDC
- DC Input Voltage - Nominal : 12VDC.
- Side Indicator Input Voltage-12VDC.
- HB & LB Indication Input Voltage : 12VDC.
- CAN Inputs : CAN ID required for communication.
Environmental:
- Wide Operating Temperature Range: -40oC to +85oC
- Mechanical Parts- Top Cover, Rubber Button, Base Housing, Self-Tapping Screws, Mounting Studs.
- Overall Dimensions- 157mm x 80mm x 33mm (Without Mounting studs).
- Weight- 270 Gram Approx.
- As per requirement, connector and length of the wire can be changed
Advantage:
- Warns battery Level
- Indicates System Issues
- Keeps Drivers Safe
- Reminds Safety Precautions
- Monitor vehicle status
- IP 65
